Besides our high quality auditorıum seats we are also producing in our factory Acoustic wooden panels for ceiling and wall.

Here we would like to share with you our products and their technical details.
Please contact us for more details and we will send you an offer according your project demand.
Please note: Need design? we provide the design service by our excellent architect Dr. Islam Abohela.

Need installation? No problem! We also provide installation by sending our team to your country.

Where can our Acoustic wooden panels can be used?

In the ceiling and wall of:  Conference rooms, theaters, wedding halls, cinemas, opera houses, shopping malls, restaurants, radio and TV studios, offices, crowded offices, hotline centers, call centers, shooting ranges, fitness centers, call centers, swimming pools, wedding rooms, conservatory, study halls.



Akustima101

Acoustic101

Acoustima101EN



Akustima102

Acoustic102

Acoustica102EN

Akustima103

Acoustic103

Acoustic103EN

Akustima104

Acoustic104

Acoustic104EN

Akustima105

Acoustic105

Acoustic105EN

Akustima106

Acoustic106

Acoustic106EN













Akustima107

Acoustic107



Akustima108

Acoustic108

Akustima109

Acoustic109

Akustima110

Acoustic110

Akustima111

Acoustic111

Akustima112

Acoustic112

Akustima113

Acoustic113

Akustima114

Acoustic114

Akustima222

Acoustic222

Akustima223

Acoustic223

Akustima224

Acoustic224

Akustima225

Acoustic225

Akustima226

Acoustic226

Akustima227

Acoustic227

Akustima228

Acoustic228

Akustima229

Acoustic229

Akustima230

Acoustic230

Akustima231

Acoustic231

Akustima232

Acoustic232

Akustima233

Acoustic233

NATURAL VENEER COLOR CHART

Natıral Colors chart acoustimaMDF LAMINATE COLOR CHART

MDF chart acoustimaMDF chart acoustima2MDF chart acoustima3MDF chart acoustima4MDF chart acoustima5MDF chart acoustima6MDF chart acoustima7MDF chart acoustima8

TECHNICAL SPECIFICATIONS FOR ACOUSTIC WALL WOODEN PANELS

THE CLASSIC SYSTEM:

Technical Specifications: Sizes are from 600x600mm to 1500-300mm.

Special dimensions can be produced upon request.

Raw Material: Painted, melamine and natural veneered MDF

Acoustic Fabric: Soundtex

Fire Class: DIN4102-B2, natural coating fire retardant polish application B1.

Carrier Systems: Tongue and Groove joint system.

System: Acoustic panels are mounted tongue and groove joint system.

Panels are placed on the wall  with air staple guns and strong glue.

THE 1 AND 2  CLASSIC SYSTEMS FOR ACOUSTIC WALL WOODEN PANELS

ARE BELOW:

CLASSIC SYSTEM 1:

system-acoustima-drawing1-1-300x208 (1)System2-acoustima2-1-300x300

CLASSIC SYSTEM 2:

system-acoustima-drawing1-1-300x208 (1) System2-acoustima2-1-300x300

 TECHNICAL SPECIFICATIONS FOR ACOUSTIC WALL WOODEN PANELS

THE OMEGA SYSTEM:

Technical Specifications: Sizes are from 600x600mm to 1500-300mm.

Special dimensions can beproduced upon request.

Raw Material: Painted, melamine and natural veneered MDF

Acoustic Fabric: Soundtex

Fire Class: DIN4102-B2, natural coating fire retardant polish application B1

Carrier Systems: Tongue and Groove joint system.

System:  Acoustic panels are mounted with aluminium profiles. These profiles are screwed to the box profiles and engaged with panels by screws.

The-modern-system-for-acoustic-wall-acoustima1-1-174x300 The-modern-system-for-acoustic-wall-acoustima2-1-175x300 The-modern-system-for-acoustic-wall-acoustima3-1-178x300

Top Finishing Details:

Top-Finishing-Details-acoustima-modern-system1-1-276x300Top-Finishing-Details-acoustima-modern-system2-1-272x300Top-Finishing-Details-acoustima-modern-system3-1-273x300

Corner Finishing Details:

Corner-Finishing-Details-acoustima1-1-273x300Corner-Finishing-Details-acoustima3-1-272x300Corner-Finishing-Details-acoustima4-1-273x300

Bottom Finishing Details:
Bottom-Finishing-Details-acoustima-1-272x300

kon-06kon-04kon-03kon-02

TECHNICAL SPECIFICATIONS FOR THE 1 , 2 AND 3  CLASSIC SYSTEMS FOR ACOUSTIC CEILING WOODEN PANELS:


System: In our classic system, panels are placed from the top with T15, T24 and T15 grooved carriers. This carriers are visible between panels.

Every panels  are independetly removable by hand without any help.

That provides quick and easy access to existing installation.

Thecnical Specifications: Sizes are from 600×600 mm to 1500x3000mm.

Special dimensions can be produced upon request.

Raw Materials: Painted, melamine and natural veneered MDF

Fire Class: DIN4102-B2 natural coating fire retardant polish application B1

Carrier System: T15, T24 and T15 grooved

Acoustic Fabric: Soundtex



CLASSIC SYSTEM 1:

classic-system1-for-ceiling-acoustima-1-209x300classic-system1-first-drawing-1-300x212classic-system1-second-drawing-1-300x212 (1)

CLASSIC SYSTEM 2:

classic-system2-for-ceiling-1-209x300Classic-system-2-for-Ceiling-first-drawing-1-300x212Classic-system-2-for-Ceiling-second-drawing-1-300x212

CLASSIC SYSTEM 3:

Classic-system3-ceiling-1-209x300Classic-System-3-for-Ceiling-first-drawing-1-300x212Classic-System-3-for-Ceiling-second-drawing-1-300x212

Picture34Picture42Picture36




TECHNICAL SPECIFICATIONS FOR THE MODERN SYSTEM FOR ACOUSTIC CEILING WOODEN PANELS:


System: In our modern system, panels with special corner details are placed  with T24 carriers.

This carriers are invisible between panels.

Every panels are independetly removable by hand without any help.

That provides quick and easy access to existing installation.

Thecnical Specifications: Sizes are from 600×600 mm to 1500x3000mm. Special dimensions can be produced upon request.

Raw Materials: Painted, melamine and natural veneered MDF

Fire Class: DIN4102-B2 natural coating fire retardant polish application B1

Carrier System: T24

Acoustic Fabric: Soundtex

MODERN SYSTEM:

Picture37Picture38Picture39

Picture34Picture42Picture36

TECHNICAL SPECIFICATIONS FOR THE PRESTIGE SYSTEM FOR ACOUSTIC CEILING WOODEN PANELS:


System: In this system, Z carriers are mounted to the box profile and wooden panels are put on Z profiles with its special corner details.

Here these carriers are not visible.

All panels are independently removable by hand without the need of any apparatus.

This provides quick and easy access to existing installations.

Technical Specifications: Sizes are from 600x600mm to 1500-300mm.

Special dimensions can be produced upon request.

Raw Material: Painted, melamine and natural veneered MDF

Fire Class: DIN4102-B2, natural coating fire retardant polish application B1

Carrier System: Aluminum Z Profile

Acoustic Fabric: Soundtex

Picture44Picture45Picture41Picture42Picture36

kon-05




TECHNICAL SPECIFICATIONS FOR LINEER PANELS ALUMINIUM PIPING SYSTEM:

lineer piped system

System:  Our linear panels are fastened with aluminum pipe carriers  at desired intervals.

After making the panels, each panel is attached to each other through with a special clips and hanged on the ceiling.

All panels are independently removable by hand without the need of any apparatus.

That provides quick and easy access to existing installations.

Technical Specifications: Desired size can be produced.

Raw Material: MDF laminated coating, lacquer coating over Ayous tree.

Fire Class: DIN4102-B2, fire retardant varnish application B1 over Ayaous tree.

Carrier Systems: Aluminum piped profile.





TECHNICAL SPECIFICATIONS FOR LINEER PANELS HOOK-ON SYSTEM:

System:  Our linear panels are fastened with hook-on carriers at desired intervals. After making the panels, each panel is attached to each other with hook-on profiles and hanged on the ceiling. All panels are independently removable by hand without the need of any apparatus, that provides quick and easy access to existing installations.

Technical Specifications: Desired size can be produced.

Raw Material: MDF laminated coating, lacquer coating over Ayous tree.

Fire Class: DIN4102-B2, fire retardant varnish application B1 over Ayaous tree.

Carrier Systems: Galvanize painted hook-on system



Acoustic Wooden Door

acoustic wooden door- acoustima

Description:

Acoustic Wooden Doors are made for sound insulation.

Our Acoustic Wooden  doors will perform in many different acoustic value as Rw 55 decibels

This acoustic values ​​are sufficient to ensure that most of the sound insulation requirements.

If you have a specific need, our team will work with you to find the right solution.

Usage areas:

Entrance and exit doors of: Conference rooms, theaters, wedding halls, cinemas, opera houses, shopping malls, restaurants, radio and TV studios, offices, crowded offices, hotline centers, call centers, shooting ranges, fitness centers, call centers, swimming pools, wedding rooms, conservatory, study halls, hotel rooms, sound recording studios.

Or: Auditorium , Multiplexes and Home Theatre, Music Halls and Concert Venues, Hotels, Offices and Factories, Public Buildings, Museums and Galleries , Hospitals and Nursing Homes , Schools, Colleges and Universities.

Technical details:

Technical details Will be shared according to your project demand

We offers a widest range of acoustic wooden doors which is a fantastic combination of

architectural elegance and certified acoustic performance.




Application of Acoustic wooden panels for modular partitions systems:

Can be designed according your project demand:

Picture50Picture51



acoustima photo7
